The Freq Shifter panel in the Plug-in Strip.
The Freq Shifter in the Control area.
Parameter Description
FREQ Section
Coarse This is used to define the basic frequency of the Freq Shifter.
Fine Fine-tune the frequency here.
OUTPUT Section
Feedback Adjusts the amount of output signal fed back into the input. Increasing
this parameter will increase the intensity of the effect.
Stereo This parameter widens the stereo field of the effect.
Invert Inverts the settings of the Freq Shifter.
Mix Mix lets you adjust the amount of the effect in relation to the dry original
audio signal.
Effect Reference
Modulation Effects
