Parameter Description
MAIN Section
Frequency This defines the center frequency of the Phaser.
Feedback Adjusts the amount of output signal fed back into the input.
8Pole Activating this causes the Phaser to use the 8Pole mode, resulting in a
more intense phasing effect.
MOD Section
Amount This defines how much the Phaser gets modulated by the modulation
source.
Source Here you can select the modulation source of the Phaser: available options
are LFO, LFO Sync, and Envelope. Depending on your selection, the pa-
rameter to the right will change.
Speed (LFO) Defines the speed of the LFO in a range from 0.03 Hz up to 8 Hz.
Speed (LFO Sync) Defines the speed of the LFO in note values from 16/1 (one cycle every 16
bars) up to 1/16 note.
Shape (Envelope) Change the shape of the envelope here.
Stereo This parameter widens the stereo field of the effect.
OUTPUT Section
Mix Mix lets you adjust the amount of the effect in relation to the dry original
audio signal.
The Phaser on the controller.
