The Metaverb in the Control area.
Parameter Description
ROOM Section
Size Adjust the size of the virtual room here.
EQ Section
Low Low band EQ to cut or boost bass frequencies.
High High band EQ to cut or boost high frequencies.
POSITION Section
Pan This pans the dry signal. This is useful because the dry signal can not be
panned after the effect without panning the reverb itself, which is unnatu-
ral.
OUTPUT Section
Mix Mix lets you adjust the amount of the effect in relation to the dry original
audio signal.
The Metaverb on the controller.
Effect Reference
Spatial and Reverb Effects
