12.4.3 Reflex
This is a special resonating reverb. At moderate settings the Reflex can be useful to emulate
small, “tight” rooms. At more extreme settings, it can produce interesting artificial, metallic
textures.
Automating the Color parameter usually yields very pleasing results.
The Reflex panel in the Plug-in Strip.
The Reflex in the Control area.
Parameter Description
ROOM Section
Color At lower settings, the general sound is a bit more muffled; the higher the
settings, the brighter it sounds.
Smooth With this parameter, you can soften the metallic character of Reflex.
Size Adjust the size of the virtual room here.
Effect Reference
Spatial and Reverb Effects
MASCHINE STUDIO - Manual - 561
