The Reverb in the Control area.
Parameter Description
ROOM Section
Room This allows you to choose one of four basic characteristics of the Reverb:
General, Bright, Guitar, and Shatter.
Size Adjust the size of the virtual room here.
EQ Section
Low Low band EQ to cut or boost bass frequencies.
High High band EQ to cut or boost high frequencies.
POSITION Section
Pan This pans the dry signal. This is useful because the dry signal can not be
panned after the effect without panning the reverb itself, which is unnatu-
ral.
Stereo This parameter widens the stereo field of the effect.
OUTPUT Section
Freeze Enabling Freeze both mutes the dry signal and traps the current state of
the Reverb output in a temporary buffer to make it last much longer. This
is a powerful tool for playing live: By simultaneously tweaking the Mix knob
nearby, you can create striking breaks! Setting the EQ’s Low and High con-
trols to generous values will further increase the effect.
Mix Mix lets you adjust the amount of the effect in relation to the dry original
audio signal.
Effect Reference
Spatial and Reverb Effects
MASCHINE STUDIO - Manual - 563
