The Plate Reverb in the Control area.
Parameter Description
MAIN Section
Pre Delay Adjusts the time between the original signal and the early reflections.
Decay Adjusts the damping of the plate, which directly affects the decay time of
the reverb.
EQ Section
Low Shelf Controls the low-frequency content in the reverberated signal.
High Damp Adjusts the damping of the high frequencies in the reverberated signal.
OUTPUT Section
Mix Mix lets you adjust the amount of the effect in relation to the dry original
audio signal.
The Plate Reverb on the controller.
Effect Reference
Spatial and Reverb Effects
MASCHINE STUDIO - Manual - 565
