Unit Page
The Beat Delay in the Control area: Unit page.
Parameter Description
UNIT Section
Unit Defines the unit used by the Time and Offset parameters on the Main
page.
The Beat Delay on the controller: UNIT page.
12.5.2 Grain Delay
By chopping the input into small “grains” and rearranging them as a cloud, the Grain Delay is
useful for creating ambient textures. Increase Size, Space and Density to quickly transform any
sound into an evolving ambient texture. As a unique experimental effect, it is best experienced
firsthand. Please note that in the Control area and on your controller the Grain Delay parame-
ters are spread over two pages.
Effect Reference
Delays
MASCHINE STUDIO - Manual - 568
