The Grain Delay panel in the Plug-in Strip.
Main Page
The Grain Delay in the Control area: Main page.
Parameter Description
GRAIN Section
Pitch Determines the pitch of the grains: low values result in a deep, slowly re-
peating grain, high values speed up the grain, making it sound faster and
higher.
Size Defines the length of the grains.
Jitter Introduces artifacts into the grains.
Reverse Produces a reverse playback of the grain.
CLOUD Section
Space Determines the spacing between the grain clouds: the higher the value, the
bigger the space between the clouds.
Density Creates a more “dense” cloud: higher values create feedback-like effects.
Effect Reference
Delays
MASCHINE STUDIO - Manual - 569
