Parameter Description
Mod The amount of modulation introduced to the grain cloud.
Mix Mix lets you adjust the amount of the effect in relation to the dry original
audio signal.
The Grain Delay on the controller: MAIN page.
Output Page
The Grain Delay in the Control area: Output page.
Parameter Description
OUTPUT Section
Stereo This parameter widens the stereo field of the effect. Values go from 0 %
(no stereo) to 100 % (full stereo).
Effect Reference
Delays
MASCHINE STUDIO - Manual - 570
