Parameter Description
MASTER Section
On Enables the effect. Every time this control is switched on, the Grain
Stretch effect buffers incoming audio for 32 x 1/16th step.
TIME Section
Stretch Defines the time-stretch amount. Set to 50.0 % for half speed.
Loop Sets a loop length, in 1/16th steps.
PITCH Section
Pitch Adjusts the pitch of the grains.
Link When on, grain size is corrected by the pitch.
Size Adjusts the size of the grains.
OUTPUT Section
Mix Mix lets you adjust the amount of the effect in relation to the dry original
audio signal.
The Grain Stretch on the controller.
12.5.4 Resochord
The Resochord is a bank of 6 comb filters, each of which is individually tuned according to the
selected chord. The results are most effective with non-melodic content (like drums) as the Re-
sochord will print its own harmonic content on to any input material.
Effect Reference
Delays
MASCHINE STUDIO - Manual - 572
