The Resochord panel in the Plug-in Strip.
The Resochord in the Control area.
Parameter Description
PITCH Section
Mode Here you can select between the two modes of the Resochord: Chord and
String. In Chord mode, the 6 combs are tuned according to various chords.
In String mode, the 6 combs are centered around one frequency and can
be spread for an intense chorus-like effect. Depending on your selection
the other parameters in the Pitch area will change.
Spread (String mode) Allows you to define how big the difference in tuning is between combs.
Style (Chord mode) You can select between different chord-styles such as minor or major.
Chord (Chord mode) Here you can choose from different chords to be applied to your audio sig-
nal.
Tune It allows you to transpose the Resochord in semitones.
COLOR Section
