13.1.1 Arranger Overview
In the MASCHINE software, the Arranger is where you define what should play with what, and
when.
This overview of the Arranger introduces you its main parts and control elements.
An overview of the Arranger.
(1) Mix View button: Click the Mix View button to switch the MASCHINE software between the
Arrange view and the Mix view. The Arranger is visible only in Arrange view, i.e. only if the Mix
View button is disabled.
(2) Project name: The name the project is displayed here.
(3) Scene Manager button: Click this down-pointing arrow to open the Scene Manager. The
Scene Manager allows you to organize your Scenes and provides all necessary Scene manage-
ment functions. See section ↑13.2, Managing Scenes.
(4) Group List: All the Groups of your Project are listed here. In the row at the right of each
Group you can choose which of its Patterns must be played in each Scene. You do this by cre-
ating Clips (7), each of them referencing a particular Pattern. See section ↑13.1.5, Creating
and Removing Clips.
