The Follow button lights up in the MASCHINE Header. The Arranger will now switch to
the next portion of your Project (with the same zoom factor) as soon as the playhead rea-
ches the end of the portion currently displayed. This way, you always see the portion of
your Project that is currently played.
The Follow function will be automatically disabled as soon as you manually scroll in the Ar-
ranger or the Pattern Editor (in the software or from your controller).
The Follow function affects both the Pattern Editor and the Arranger simultaneously (see sec-
tion ↑7.1.3, Following the Playback Position in the Pattern for more information on the Follow
function in the Pattern Editor).
13.1.3.1 Following the Playback Position on your MASCHINE STUDIO Controller
To follow the playhead position in the Event area during playback:
1. Press ARRANGE to enter Arrange mode.
2. Press Button 3 (FOLLOW).
→
Both Button 3 and the FOLLOW label underneath light up. In the software the Arranger will
now switch to the next portion of your Project (with the same zoom factor) as soon as the
playhead reaches the end of the portion displayed. You can press ARRANGE again to
leave Arrange mode: the Follow function will stay active.
The Follow function will be automatically disabled as soon as you manually scroll to anoth-
er portion of the Pattern.
The Follow function simultaneously affects various displays in the software and on your con-
troller:
▪ In the software the Follow function affects both the Pattern Editor and the Arranger.
▪ On your controller the Follow function affects the displays in Arrange mode (for both SCENE
and PATTERN pages), Events mode, Step mode, and Note Repeat mode. Additionally, in
Step mode the Follow function affects the pads: With Follow enabled, when the playhead
has gone across all 16 steps shown by the pads on your controller, the pads automatically
switch to the next 16 steps of the Pattern, if any. See section ↑7.4.2, Creating Events/
Notes for more information on Step mode.
