Setting Description

Metronome Settings

Down Beat Sample and Up Beat

Sample

Here you can select audio files to be used as up and down beat of the met-

ronome, respectively. The fields display the locations of the audio files se-

lected for use. Click the fields to select other files. Click the little crosses

on the right of the fields to remove the custom audio files and use the de-

fault metronome sounds instead.

Pattern Length

Bars Here you can define the default length of new Patterns. The length is

measured in bars:beats:16ths. To adjust the value, click the desired num-

ber (bars, beats or 16ths) and drag your mouse vertically. See ↑7.1.6, Ad-

justing the Pattern Grid and the Pattern Length for more information on

the Pattern Length.

Template Project

Standalone Here you can select a Project to load automatically when you start a new

Project in MASCHINE used as a stand-alone application. The field displays

the location of the Template Project selected for use. Click the folder icon

to select another Template Project. Any Project file can be used as a tem-

plate, this can be from the MASCHINE Library or you could create a file,

for example with your preferred instruments and effects already loaded into

the Plug-in slots. If you have already set a Template Project, click the

cross icon to unset it and start new Projects from scratch instead.

Plug-in Here you can select a Project to load automatically when MASCHINE is

used as a plug-in within a Digital Audio Workstation. The field displays the

location of the Template Project selected for use. Click the folder icon to

select another Template Project. Any Project file can be used as a tem-

plate, this can be from the MASCHINE Library or you can create a file, for

example with your preferred instruments and effects loaded into the Plug-

in slots. If you have already set a Template Project, click the cross icon to

unset it and start new Projects from scratch instead.

2.5.3 Preferences – Library Page

The Library page allows you to edit the locations of all MASCHINE library files (both factory

and user) that appear in the LIBRARY pane of the Browser.

Basic Concepts

Preferences

MASCHINE STUDIO - Manual - 59
