◦ If playback is off the playhead immediately jumps to the beginning of the selected
Scene. If playback is on the playhead jumps according to the Perform Grid settings.
For more info on the Loop Range see section ↑13.3.1, Selecting a Loop Range. For more
info on the Perform Grid settings see section ↑13.3.2, Jumping to Other Scenes.
13.2.2.1 Selecting Scenes and Scene Banks on the MASCHINE STUDIO Controller
Selecting a Scene Bank
To select a Scene located in another Scene bank than the one currently selected, you fist need
to select that other Scene bank:
►
Press SCENE + Button 7 or 8 to select the previous or next Scene bank, respectively.
If the last Scene bank is selected and not empty, pressing Button 8 will create a new, emp-
ty Pattern bank — see section ↑13.2.5, Creating and Deleting Scene Banks for more infor-
mation.
You can also select Scene banks in Scene Arrange mode: press ARRANGE then Button 1
(SCENE), then use Button 7 and 8 as described above.
Selecting a Scene
►
To select a Scene in the current Scene bank, press SCENE + the dim lit pad correspond-
ing to the cell of the desired Scene on the right display. Alternatively you can press
SCENE + Page buttons to select the previous/next Scene.
You can also select Scenes in Scene Arrange mode: press ARRANGE then Button 1 (SCENE),
then use the pads or the Page buttons as described above.
Upon your selection, the following happens:
▪ The Pattern Editor displays the Pattern corresponding to the Clip for the focused Group in
this Scene. If there is no Clip for the focused Group in the Scene you have just selected,
the Pattern Editor is empty.
▪ If you have selected the Scene by pressing a pad, or if you have selected a Scene outside
the current Loop Range via the Page buttons:
Creating a Song Using Scenes
Managing Scenes
MASCHINE STUDIO - Manual - 605
