To delete a Scene in the Scene Manager, hover the slot of the desired Scene with your
mouse and click the little cross that appears on the right of the slot:
13.2.4.1 Deleting Scenes on the MASCHINE STUDIO Controller
To delete a Scene on your controller:
1. Press and hold SCENE to enter Scene mode.
2. Press Button 7 and 8 to select the desired Scene bank.
3. Press the pad corresponding to the Scene you want to delete. Alternatively you can select
the Scene by pressing the Page buttons.
4. Press Button 6 (DELETE).
→
The Scene is deleted with all its Clips. The next Scenes shift ahead to fill the gap.
Alternate Method
1. Press and hold SCENE to enter Scene mode.
2. Press Button 7 and 8 to select the desired Scene bank.
3. Press ERASE + the pad corresponding to the Scene you want to delete.
→
The Scene is deleted with all its Clips. The next Scenes shift ahead to fill the gap.
If the desired Scene bank is already selected (or if there is only one Scene bank), this alter-
nate method can be simplified as follows: Press ERASE + SCENE + pad to delete the cor-
responding Scene!
You can also delete Scenes in Scene Arrange mode: press ARRANGE then Button 1 (SCENE)
to enter Scene Arrange mode, then follow either of the procedures described above.
Creating a Song Using Scenes
Managing Scenes
MASCHINE STUDIO - Manual - 611
