The Scene takes its new place. In Scene mode you can now select this Scene via the pad
corresponding to its new location.
You can also move Scenes in Scene Arrange mode: press ARRANGE then Button 1 (SCENE)
to enter Scene Arrange mode, then follow the procedure described above.
13.2.9 Clearing Scenes
Clearing a Scene allows you to remove all its Clips, leaving the Scene empty. Clearing Scenes
is only available from within the software.
While deleting a Scene removes it entirely from your arrangement, clearing it only removes
its content — the Scene stays in your arrangement, but empty. For more info on deleting
Scenes, see section ↑13.2.4, Deleting Scenes.
To clear a Scene:
1. Right-click ([Ctrl]-click on Mac OS X) the name of the desired Scene in the Arranger or in
the Scene Manager, and select Clear from the context menu.
→
The Scene is cleared.
13.2.10 Duplicating, Copying, and Pasting Scenes
Duplicating a Scene will insert a new Scene slot next to it containing the exact same Scene
and settings (name, color). The following Scene slots will shift one step to the right.
Creating a Song Using Scenes
Managing Scenes
MASCHINE STUDIO - Manual - 618
