The User pane shows all user libraries currently used. These include MASCHINE’s standard
user directory as well as any other user directory you might have defined. These libraries will
appear in the User view of the Browser’s Library pane.
Element Description
Location column Shows the path of each library. If you have moved any library to another location
on your computer, click the folder icon on the left of that library and select its
new path.
Alias column Shows the alias stored for each library. Click an alias to edit it. Defining aliases
for your user folders is not mandatory, but it can be of great help when working
on different computers (see description below). After adding a location (see Add
below), click the field in the new row and in the Alias column to set the alias for
that new location. The alias of the default user folder, Standard User Directory,
cannot be edited — this is the location where all your user files will be stored by
default.
Add button Click Add to manually add directories to the user library. See below for more de-
tails.
Remove button Click Remove to remove the selected user library. Files will only be removed
from the MASCHINE Browser, not from your hard disk.
Rescan button If you have made any change to a library (e.g., added/removed files), select it in
the list and click the Rescan button to rescan that library.
You can resize the Preferences panel at your convenience using the usual method on your
operating system. You can also resize each column by clicking and dragging the limit be-
tween both column headers.
Using Aliases
The aliases available in the Alias column act as references to the paths shown in the Location
column. When you save a Project, the saved data includes both the path and the alias for each
file used in the Project. This will allow you to use a Project on different computers even if the
files used in the Project (e.g., Samples) are stored in different locations on each computer:
Simply define the same alias for these locations on each computer, and MASCHINE will re-
place the path saved on the first computer with the path set to the same alias on the second
computer in order to retrieve the files on this second computer, therefore avoiding the possibil-
ity of missing Samples.
