14.2.3.1 Arming, Starting, and Stopping the Recording on Your Controller

Starting and stopping the recording.

►

Press Button 5 (START) to arm the recording.

After the recording has been armed, its behavior will depend on the recording mode you have

selected (via the MODE selector, see section ↑14.2.2, Selecting the Source and the Recording

Mode above):

▪ When recording in Sync mode:

◦ The recording will start at the next bar. Until then Button 5 flashes, the label under it

reads WAITING, and a WAITING FOR NEXT BAR… message appears underneath.

◦ Once the recording has started, the audio is recorded for the duration set by the

LENGTH control (see section ↑14.2.2, Selecting the Source and the Recording Mode

above). You can also press Button 5 (STOP) beforehand to stop the recording at the

next bar, or Button 6 (CANCEL) to cancel the recording (in that case the recorded audio

will not be saved).

▪ When recording in Detect mode:

◦

The recording will start as soon as the input signal exceeds the THRESHOLD value. Until

then Button 5 flashes, the label under it reads WAITING, and a WAITING FOR INPUT… mes-

sage appears underneath. During this waiting phase you can also start the recording

manually by pressing Button 5 (WAITING) or cancel the recording by pressing Button 6

(CANCEL).

Sampling and Sample Mapping

Recording a Sample

MASCHINE STUDIO - Manual - 643
