The waveform display and the information bar displaying a recording.
(1) Waveform display
Shows the waveform of the recording currently selected in the Recording History (5) — by de-
fault your last recording:
▪ Use the scroll wheel of your mouse to zoom in/out. You can also use the zooming scroll
bar (2).
▪ When the Sample is played back (e.g., by pressing the pad or by clicking the little play
icon in the information bar (4)), a playhead indicator (white vertical line) shows you the
current play position within the waveform.
▪ Right-click (Mac OS X: [Ctrl]-click) anywhere in the waveform to open a context menu with
the following commands:
Command
Description
Open containing folder Opens the folder on your hard disk containing the Sample, providing quick ac-
cess to the original file.
Save Sample As… Opens a Save Sample As dialog allowing to save the recorded Sample under an-
other name and/or to another location on your computer.
(2) Zooming scroll bar
