The EDIT page on the controller, page 2 of 2: adjusting the selection range of the Sample.
Parameter Description
START (Knob 1)
Adjusts the start point of the selection range in the Sample.
END (Knob 2)
Adjusts the end point of the selection range in the Sample.
Hold SHIFT when turning the Knobs to adjust the parameters in finer increments.
On the right display, the selection range is highlighted.
Changing the play range automatically resets the selection range to the new play range.
Audio Editing
The EDIT page provides several audio editing functions to process your Sample. Available via
Button 5–8 above the right display, these functions are described in detail in the next section
↑14.3.2, Audio Editing Functions.
14.3.2 Audio Editing Functions
In the Edit page, the Audio Toolbar provides various audio functions. These will be performed
on the selected region of the Sample, as defined by the Start and End parameters of the SE-
LECTION RANGE section (see ↑14.3.1, Using the Edit Page above).
Sampling and Sample Mapping
Editing a Sample
