Element Description
Plug-in column Lists all available VST/AU plug-ins from the directories specified in the Locations
pane (see below). This includes all enabled or disabled 32-bit VST/AU plug-ins,
when MASCHINE is running in 32-bit mode or otherwise all enabled or disabled
VST/AU 64-bit plug-ins, when MASCHINE is running in 64-bit mode.
On the left of each plug-in in the list, a checkbox allows you to enable/disable
this plug-in in MASCHINE. When a plug-in is disabled, it will not be available for
loading in MASCHINE.
Default Config column For each plug-in you can set a default preset that will be loaded with this plug-in
when you load it. Click the folder icon on the left to choose a default plug-in pre-
set. You can also save a preset as default for the Plug-in via the Save As De-
fault… entry in the Plug-in menu. If no default is set here, the parameters of this
plug-in will be auto-mapped when loading it into a plug-in slot.
To remove a default plug-in preset, click the little cross on the right.
Rescan button If you have changed the content of any directory specified in the Locations pane
(see below), you should rescan your plug-in directories in order to keep the list of
available external plug-ins up to date. Clicking Rescan will check the integrity of
your plug-ins and allow you to automatically detect plug-ins that were added or
removed, or deselect any plug-ins that are not working correctly for any reason.
Note that the scan will ignore the plug-ins that are disabled in the list above.
Manager Pane: Use NI Audio Units Checkbox (Mac OS X Only)
On Mac OS X, the Manager pane contains an additional Use NI Audio Units checkbox. Check
this box to include the Audio Units (AU) versions of your Native Instruments plug-ins in the
software’s Plug-in menus and in the controller’s Plug-in Browser:
▪ If this checkbox is disabled (default setting), the AU versions of your Native Instruments
plug-ins are still listed in the list above but they are disabled (checkbox unchecked):
These Plug-ins won’t appear in the Native Instruments submenu of the Plug-in menus
(software) or in the Plug-in Browser (controller). Additionally, the remaining entries for
Native Instruments Plug-ins (all of them VST) won’t display the (VST) mention next to
their name.
