Parameter Description

FIX DC

This removes the DC offset. DC offset (“Direct Current offset”) is an undesirable

constant shift in the signal level that might be introduced by some audio pro-

cessing units. This offset can notably waste some of the available headroom.

SILENCE

This silences the selected region of the Sample.

CUT

This deletes the selected region from the Sample and places it into the clipboard

for later use.

COPY

This copies the selected region of the Sample to the clipboard for later use.

PASTE

This pastes the cut/copied region of the Sample, replacing the region of the

Sample currently selected.

DUPLICATE

This duplicates the selected region of the Sample. The copy is placed right after

the original region.

STRETCH

This allows you to apply time stretching and/or pitch shifting to the selected re-

gion of the Sample. See below for a detailed description.

Time Stretching / Pitch Shifting

When STRETCH is selected, pressing Button 7 (SETTINGS) allows you to adjust the parameters of

the time stretching / pitch shifting function before applying it to the selected region. Use Knob

1–8 to adjust the parameters. Pitch shifting and time stretching can be applied independently.

Parameters for the Stretch function.

Following parameters are available via Knob 1–8:

Sampling and Sample Mapping

Editing a Sample
