Parameter Description
STRETCH section
TUNE
Adjusts the detuning (pitch shifting) to be applied (in semitones and cents). Leave
this value to 0.00 to leave the original pitch untouched.
FORMANT C
(Formant Correction)
Enables/disables the formant correction. Formant correction allows the pitch-shif-
ted audio to retain the timbre (or “color”) of the original audio as much as possi-
ble. This is especially useful for melodic instruments.
MODE
Selects from the two available time shifting modes.
BEAT: In Beat mode, the new tempo is defined relative to the time signature (the
beats and bars) of the original audio. This can be useful if you sampled a loop
with a clearly defined rhythm (e.g., a drum loop).
FREE: In Free mode, the new tempo is defined independently from the time signa-
ture of the source. This is more suited for non-rhythmic Samples. In this mode on-
ly one parameter is available: SPEED (see below).
AUTO DTCT
(Auto Detection, Beat
mode only)
If AUTO DTCT (Auto Detection) is enabled, MASCHINE automatically detects the
tempo of the original audio.
SRC BPM
(Source BPM, Beat
mode only)
SRC BPM (Source BPM) allows to define the tempo of the original audio (in BPM).
This tempo is defined in different ways according to the AUTO DTCT value:
If AUTO DTCT is enabled, you can set the length (in bars) of the original audio. You
can choose between 1/2, 1, and 2 bars. The number between brackets indicates
the resulting tempo (in BPM) derived from the number of bars you have set and
the computed tempo value.
If AUTO DTCT is disabled, you can directly define the tempo of the original audio (in
BPM).
NEW BPM
(Beat mode only)
Defines the target tempo of the time-shifted audio (in BPM).
