14.4.2 Adjusting the Slicing Settings
At the bottom of the Slice page, you can adjust the settings used to define where the various
Slices will be created in the Sample.
Adjust the slicing settings at the bottom of the Slice page.
Any change to these settings will directly affect the number and position of the Slice markers
displayed on the waveform above.
At any time you can prelisten to the proposed Slices on the Cue bus (see section ↑9.2.6, Using
the Cue Bus for more information) by pressing the lit pads or clicking the Slices on the wave-
form display.
Following parameters are available:
Parameter Description
TIME Section
MODE Here you can select either Split, Grid, Detect or Manual:
Split mode: The Sample will be sliced into equally spread Slices.
Grid mode: The Sample will be sliced according to note values.
Detect mode: The Sample will be sliced according to its transients.
Manual mode: You can manually slice the Sample as you see fit.
SLICES (Split and Grid
mode only)
When MODE is set to Split (see above), SLICES lets you choose the amount of
Slices: 4, 8, 16 or 32.
When MODE is set to Grid (see above), SLICES lets you choose the length of the
Slices in note values: 4th, 8th,16th or 32nd notes.
SENSITIVITY (Detect
mode only)
When MODE is set to Detect (see above), SENSITIVITY lets you adjust the sensi-
tivity of the transient detection. Higher values will cause more Slices to be de-
tected because more transients will be recognized, lower values will result in less
Slices. This parameter should be adjusted until all the musically significant sli-
ces are being detected in the waveform.
