Parameter Description

BPM (BPM Mode) Selects how the tempo is defined: If you select AUTO, MASCHINE will calculate

the tempo automatically. If you select MANUAL, you can enter the tempo in BPM

manually.

ADJUST If BPM is set to AUTO, you can choose between the tempo that MASCHINE detec-

ted, or half or double of that tempo. If BPM is set to MANUAL, you can adjust the

tempo manually.

When MODE is set to DETECT, a second section of parameters is available at the bottom of the

left display: the ENGINE section.

►

When MODE is set to DETECT, press the Right Page button to show the ENGINE section.

The ENGINE section.

This ENGINE section contains a single parameter: ZERO-X.

Parameter Description

ENGINE Section (Detect mode only)

ZERO-X (Zero Crossing, De-

tect mode only)

When MODE is set to DETECT, activate ZERO-X to force the detected Slices to be cre-

ated on the closest locations where the audio signal crosses the zero value. This

can be helpful to avoid clicks when playing back Slices in another sequence.

14.4.3 Manually Adjusting Your Slices

In addition to the Split, Grid, and Detect modes that create Slices automatically (see section

↑14.4.2, Adjusting the Slicing Settings above), you can also adjust Slices manually using your

mouse, the waveform display, and the various edit tools at your disposal.

Sampling and Sample Mapping

Slicing a Sample

MASCHINE STUDIO - Manual - 668
