▪ The other selected Zones are highlighted in white. Their settings are not displayed any-
where, however they will be affected by your actions in the Zone List and in the Map view
(see section ↑14.5.5, Selecting and Editing Zones in the Map View for more on this).
Mouse/Keyboard Action Command
Multiple Selection
Hold [Ctrl] ([Cmd] on Mac OS X) and click
several entries in the list
Selects all clicked Zones. Click a selected Zone to deselect it
(i.e. remove it from the selection).
Hold [Shift] and click two entries Selects both Zones and all Zones in-between.
Press [Ctrl]+[A] ([Cmd]+[A] on Mac OS X) Selects/deselects all Zones in the list. When deselecting, only
the focused Zone remains selected.
Deleting Zones from the List
To remove one or more Zone(s) from the Zone List:
1. Select the Zone(s) you want to remove.
2. Press [Del] or [Backspace] on your computer keyboard.
→
The selected Zones are removed from the Zone List and from the Sample Map, and the
corresponding Samples are not used in the Sound anymore.
After you have selected the Zone(s) you want to remove, you can also use the context menu:
1. Select the Zone(s) you want to remove.
2. Right-click ([Ctrl]-click on Mac OS X) any of the selected Zones.
A menu opens up.
3. In that menu selects Delete to remove the focused Zone only, or Delete Selected to re-
move all selected Zones.
Sampling and Sample Mapping
Mapping Samples to Zones
MASCHINE STUDIO - Manual - 687
