The commands in the Sample Map menu will affect all selected Zones. The menu provides fol-
lowing commands:
Command Description
Delete Removes the selected Zone(s) from the Sample Map.
Map as Drum Kit Reduces the selected Zones to one note over the full velocity range and puts the
Zones next to each other upwards from the middle C (C3). The actual note as-
signed to each Zone depends on the Zone position in the Zone List: The topmost
Zone will be mapped to middle C (C3), the Zone underneath to C#3, etc.
14.5.6 Editing Zones in the Sample View
The Sample view is visible when the Sample View button (showing a little waveform icon at the
right of the Zone tab) is enabled.
Enable the Sample View button to see the Sample view.
The Sample view contains following elements:
Sampling and Sample Mapping
Mapping Samples to Zones
MASCHINE STUDIO - Manual - 693
