By moving the loop’s start and end points closer to each other you can shrink the loop to

very small values on-the-fly, thereby creating very interesting glitch effects in a live situa-

tion.

The loop will always stay within the play range of the Sample. Therefore, when moving the

Sample’s playback start and end points closer to each other, keep in mind that it might

also shrink the loop!

(3) TUNE / MIX section

The TUNE / MIX section contains parameters controlling pitch- and level-related aspects of the

Sample playback.

Parameter Description

TUNE Sets the tuning of the focused Zone.

GAIN Sets the gain of the focused Zone.

PAN Sets the panorama position of the focused Zone.

ROOT KEY Adjusts the root key of the focused Zone, that is the key at which the Sam-

ple will be played back at its original pitch. The root key is also indicated

by the colored key on the virtual keyboard; to change it, you can drag it to

another note on the keyboard.

(4) ENVELOPE section

This amplitude envelope can be used to get rid of clicks after slicing; you can either apply it to

the Zone of the whole Sample or to individual Zones for selected Slices.

Parameter Description

ATTACK Adjusts how quickly the Sample/Slice reaches full volume after being triggered.

DECAY Adjusts how fast the Sample/Slice dies down.

(5) MAP section

The MAP section contains the parameters defining the key and velocity ranges of the Zone.

Sampling and Sample Mapping

Mapping Samples to Zones

MASCHINE STUDIO - Manual - 697
