The ZONE page on the controller – page 1 of 5: PLAY RANGE parameters.
Parameter Description
START (Knob 1)
Adjusts the playback’s start point in the Sample of the focused Zone.
END (Knob 2)
Adjusts the playback’s end point in the Sample of the focused Zone.
►
Hold SHIFT when turning the Knobs to adjust the parameters in finer increments.
In the waveform on the right display, the regions outside the play range are grayed out.
Page 2 – LOOP Parameters
The parameters in the LOOP page allow you to define and adjust a portion that will play in loop
while the note is held.
The ZONE page on the controller, page 2 of 5: LOOP parameters.
Sampling and Sample Mapping
Mapping Samples to Zones
MASCHINE STUDIO - Manual - 699
