Parameter Description
TUNE (Knob 1)
Sets the tuning of the focused Zone.
GAIN (Knob 2)
Sets the gain of the focused Zone.
PAN (Knob 3)
Sets the panorama position of the focused Zone.
ROOT KEY (Knob 4)
Adjusts the root key of the focused Zone, that is the key at which the Sample will
be played back at its original pitch.
Page 4 – ENVELOPE Parameters
This amplitude envelope can be used to get rid of clicks after slicing; you can either apply it to
the Zone of the whole Sample or to individual Zones for selected Slices.
The ZONE page on the controller, page 4 of 5: ENVELOPE parameters.
Parameter Description
ATTACK (Knob 1)
Adjusts how quickly the Sample/Slice reaches full volume after being triggered.
DECAY (Knob 2)
Adjusts how fast the Sample/Slice dies down.
Hold SHIFT when turning the Knobs to adjust the parameters in finer increments.
Page 5 – MAP Parameters
The MAP page contains the parameters defining the key and velocity ranges of the Zone.
Sampling and Sample Mapping
Mapping Samples to Zones
MASCHINE STUDIO - Manual - 701
