Setting Description
Sound Default Selects a default color for your Sounds. In the menu you can choose the
desired color from the 16-color palette. The color selected as default is
highlighted in the menu. If you select Auto each Sound will have a differ-
ent default color. If you select Use Group Color (default setting) Sounds
will by default mirror the color of the Group they belong to.
Load with Colors Color settings are saved with your MASCHINE files (Projects, Groups,
Sounds, etc.). If you uncheck Load with Colors (checked by default), the
saved colors won’t be used next time you load the files — the loaded files
will use the default colors set in this Colors page instead.
Please note that the settings in this Colors page define default colors: These colors will only
be used when creating a new Project, resetting a Group/Sound, or when Load with Colors is
unchecked (see above). To change the color of particular objects (Sounds, Groups, Pat-
terns, Scenes) in your Project, use the Color submenu in the object’s context menu in the
software. See ↑4.2.4, Changing the Sound’s Color, ↑4.3.4, Changing the Group’s Color,
↑7.7.7, Changing the Pattern’s Color, and ↑13.2.7, Changing the Scene’s Color for more
information, respectively.
As long as an object (Scene, Sound, Group or Pattern) has the default color, this color is
not attached to the object but instead to its “position” in the respective list: In particular,
if you move the object to another position the default color will not follow the object — the
object will instead take the default color of its new position.
2.6 Audio and MIDI Settings
When MASCHINE is running as a stand-alone application, the Audio and MIDI Settings panel
allows you to configure the audio and MIDI hardware device(s) to use with MASCHINE along
with the audio routing between your audio device and MASCHINE.
►
To open the Audio and MIDI Settings panel, select the Audio and MIDI Settings… entry
from the File menu in the Application Menu Bar (or from the File submenu in the MA-
SCHINE menu).
Basic Concepts
Audio and MIDI Settings
