3. If MASCHINE is running as a plug-in in a host application, the MIDI configuration is man-

aged by the host (see section ↑2.4, Stand-Alone and Plug-in Mode). Please refer to your

host documentation to know how to configure MIDI in your host.

MIDI Indicators

On the top panel of your controller you will find four MIDI indicators in the top right corner

showing you at anytime the MIDI activity of the controller.

The MIDI indicators on the top panel of your controller.

▪ The IN indicator lights up when MIDI data is received on the MIDI IN socket of your con-

troller.

▪ The OUT1–3 indicators light up when MIDI data is sent on the MIDI OUT 1–3 socket, re-

spectively.

2.7.2

Sync to External MIDI Clock

If MASCHINE is running as a stand-alone application, it can be controlled externally via MIDI

Clock by any device that is capable of sending MIDI Clock. This could be hardware such as a

drum machine, another groovebox or sequencer, or even another software sequencer.

If you use MASCHINE as a plug-in, it is automatically synced to the host application so you

don’t have to activate external MIDI sync! See section ↑2.4, Stand-Alone and Plug-in Mode

for more information on using MASCHINE as a plug-in.

To enable this, select the Sync to External MIDI Clock entry from the File menu:

Basic Concepts

Integrating MASCHINE into Your MIDI Setup

MASCHINE STUDIO - Manual - 79
