Sync to External MIDI Clock activated.
You have to define at least one input in the Audio and MIDI Settings panel’ MIDI page to
enable Sync to External MIDI Clock.
When Sync to External MIDI Clock is checked, the Play button in the MASCHINE Header and
the PLAY button on your controller are deactivated.
If you want to configure MASCHINE to react to other MIDI messages than MIDI Clock, in
particular if you want to control MASCHINE notes and parameters via MIDI, please refer to
section ↑8.2, Using MIDI Control and Host Automation, where this is described in detail.
2.7.3 Send MIDI Clock
If MASCHINE is running as a stand-alone application, it can also send a MIDI Clock signal to
any device that is capable of receiving MIDI Clock. This could be hardware such as a drum
machine, another groovebox, or even another software sequencer.
If you use MASCHINE as a plug-in, it cannot send any MIDI Clock signal. See section ↑2.4,
Stand-Alone and Plug-in Mode for more information on using MASCHINE as a plug-in.
