To enable it, select Send MIDI Clock from the File menu:
Send MIDI Clock activated.
You can adjust the MIDI Clock offset in the MIDI page of the Audio and MIDI Settings pan-
el. See ↑2.6.2, Audio and MIDI Settings – Routing Page for more information.
If you want MASCHINE to send other MIDI messages than MIDI Clock, in particular if you
want to control other MIDI-capable devices via the notes played in MASCHINE, please refer
to section ↑8.2.4, Sending MIDI from Sounds.
2.8 Using Footswitches with Your MASCHINE STUDIO Controller
Your MASCHINE STUDIO Controller provides two footswitch inputs in the form of 1/4" sockets
on its rear panel.
Basic Concepts
Using Footswitches with Your MASCHINE STUDIO Controller
MASCHINE STUDIO - Manual - 81
