On the displays of your controller, the Browser is organized as follows:

▪ The left display allows you to narrow your search by selecting the file type, the content

type (factory or user files), as well as a product category, a product, a bank, and a sub-

bank.

▪ The right display allows to further refine your search by selecting the desired Type (and

possibly Mode) tags. It also shows you the corresponding result list. Turn the jog wheel or

Knob 8 to select any entry from the list, and press the jog wheel or Button 8 (LOAD) to load

it.

The above steps are described in detail in the following sections. In addition, on your controller

you will find most of the browsing aids available in the software, as described in section ↑3.3,

Additional Browsing Tools.

If you want to use your hardware a lot make sure you tag all the files you want to use exten-

sively! This makes it a much easier to access them using the hardware.

Browsing Your Library Using the Jog Wheel and the FUNCTION Buttons

As usual on your controller, each parameter visible at the bottom of either display can be ad-

justed by the Knob directly underneath. This is also true in Browse mode, as you will see in the

next sections.

However the Browse mode additionally provides an alternate, unified method for adjusting any

field appearing at the bottom of the displays: using the jog wheel and the two FUNCTION but-

tons below.

Browser

Searching and Loading Files from the Library

MASCHINE STUDIO - Manual - 89
