6-48 User’s Reference Guide
The screen below shows the ISDN/IDSL option for the WAN to be configured on the D3100-I or D3232.
The screen below shows the D7171’s SDSL option.
These screens show the dual WAN interfaces as a single bonded interface, and you configure them together by
selecting (Wan Module 1 and 2) Setup... and pressing Return.
Choose Interface to Configure
ISDN/IDSL (Wan Module 1 and 2) Setup...
Auxiliary Serial Port Setup...
Choose Interface to Configure
CMN SDSL (Wan Module 1 and 2) Setup...
Auxiliary Serial Port Setup...
