Monitoring Tools 7-51
CC
CC
hh
hh
aa
aa
pp
pp
tt
tt
ee
ee
rr
rr
77
77
MM
MM
oo
oo
nn
nn
ii
ii
tt
tt
oo
oo
rr
rr
ii
ii
nn
nn
gg
gg
TT
TT
oo
oo
oo
oo
ll
ll
ss
ss
This chapter discusses the Netopia D-Series’s device and network monitoring tools. These tools can provide
statistical information, report on current network status, record events, and help in diagnosing and locating
problems.
This section covers the following topics:
■ “Quick View status overview” on page 7-51
■ “Statistics & Logs” on page 7-53
■ “Event histories” on page 7-54
■ “System Information” on page 7-57
■ “SNMP” on page 7-57
QQ
QQ
uu
uu
ii
ii
cc
cc
kk
kk
VV
VV
ii
ii
ee
ee
ww
ww
ss
ss
tt
tt
aa
aa
tt
tt
uu
uu
ss
ss
oo
oo
vv
vv
ee
ee
rr
rr
vv
vv
ii
ii
ee
ee
ww
ww
You can get a useful, overall status report from the Netopia D-Series in the Quick View screen. To go to the
Quick View screen, select Quick View in the Main Menu.
The Quick View screen has three status sections:
■ General status
■ Current WAN Connection Status
■ LED Status
Note: The status sections vary according to the interface of your Netopia D-Series.
Main
Menu
Quick View
