7462L.book 1 ページ 2004年3月24日 水曜日 午前11時4分 Operating Instructions DVD Video Recorder Model No. DMR-E85H HARD DISK DRIVE Region number supported by this unit Region numbers are allocated to DVD players and software according to where they are sold. ≥The region number of this unit is “4”. ≥The unit will play DVDs marked with labels containing “4” or “ALL”. Example: 4 ALL 2 3 4 Dear customer Thank you for purchasing this product.
7462L.book 2 ページ 2004年3月24日 水曜日 午前11時4分 CAUTION! THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.
7462L.book 3 ページ 2004年3月24日 水曜日 午前11時4分 Table of contents Getting started Editing Useful features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 The remote control. . . . . . . . . . . . . . . . . . . . . . . . . . 4 Control reference guide. . . . . . . . . . . . . . . . . . . . . . 5 STEP 1 Connection . . . . . . . . . . . . . . . . . . . . . . . . . 6 STEP 2 TV Tuning . . . . . . . . . . . . . . . . . . . . . .
7462L.book 4 ページ 2004年3月24日 水曜日 午前11時4分 Accessories Getting started Please check and identify the supplied accessories. ∏ ∏ ∏ ∏ ∏ 1 Remote control (EUR7721KK0) 1 AC mains lead ≥For use with this unit only. Do not use it with other equipment. 1 RF coaxial cable 2 Batteries for remote control 1 Audio/video cable The remote control ∫ Batteries ∫ Use R6/LR6, AA, UM-3 Remote control signal sensor 20˚ 30˚ 20˚ 30˚ ≥Insert so the poles (i and j) match those in the remote control.
7462L.book 5 ページ 2004年3月24日 水曜日 午前11時4分 Control reference guide Remote control DVD TV Turn the unit on (➡ page 9) Television operations (➡page 11) VOLUME CH INPUT SELECT AV HDD 1 2 3 Select channels and title numbers etc.
7462L.book 6 ページ 2004年3月24日 水曜日 午前11時4分 STEP 1 Connection ≥The equipment connections described are examples. ≥Before connection, turn off all equipment and read the appropriate operating instructions. ≥Peripheral equipment and optional cables sold separately unless otherwise indicated.
462L.book 7 ページ 2004年3月24日 水曜日 午前11時4分 Connecting a television with AUDIO/VIDEO, S-VIDEO or COMPONENT VIDEO terminals and VCR indicates included accessories. indicates accessories not included. 1 4 are required connections. Connect in the numbered order.
7462L.book 8 ページ 2004年3月24日 水曜日 午前11時4分 STEP 1 Connection Connecting an amplifier or system component ∫ To enjoy multi-channel surround sound on DVD-Video ∫ Connection to a stereo amplifier Getting started Connect an amplifier with Dolby Digital, DTS and MPEG decoders using an optical digital audio cable and change the settings in “Digital Audio Output” (➡page 38). ≥You cannot use DTS Digital Surround decoders not suited to DVD.
7462L.book 9 ページ 2004年3月24日 水曜日 午前11時4分 STEP 2 TV Tuning 3 Í/ l Auto-Setup starts. This takes about 5 minutes. OPEN/CLOSE REC TIME SLIP HDD DVD TIME SLIP DRIVE SELECT Press [3, 4] to select the country and press [ENTER]. /x1.3 Auto-Setup CH 128 X CH W Auto-Setup in progress, please wait. RETURN: to abort DVD TV VOLUME CH INPUT SELECT RETURN AV HDD DRIVE SELECT 1 2 3 4 5 6 7 8 9 Auto-Setup is complete when you see the clock setting menu.
7462L.book 10 ページ 2004年3月24日 水曜日 午前11時4分 STEP 3 Set up to match your television and remote control 3 Press [3, 4] to select “Connection” and press [1]. Press [3, 4] to select “TV Aspect” and press [ENTER]. DVD TV VOLUME CH INPUT SELECT AV HDD Numbered buttons DRIVE SELECT 1 2 3 4 5 6 7 8 9 0 -/-- 4 DVD 5 CH Press [3, 4] to select the TV aspect and press [ENTER].
ページ 2004年3月24日 水曜日 午前11時4分 Television operation You can configure the remote control TV operation buttons to turn the television on/off, change the television input mode, select the television channel and change the television volume. Point the remote control at the television While pressing [Í TV], enter the code with the numbered buttons. e.g.
7462L.book 12 ページ 2004年3月24日 水曜日 午前11時4分 HDD and Disc information HDD and discs you can use for recording and play Type Logo Instructions Temporary storage Hard disk drive (HDD) ≥80 GB Indicated in these instructions with [HDD] — ≥You can record up to 142 hours [in EP (8 Hour) mode] (➡ page 15, Recording modes and approximate recording times). ≥You can perform chasing playback or Time Slip (➡ page 15). ≥You can record digital broadcasts that allow “One time only recording”.
ページ 2004年3月24日 水曜日 午前11時4分 Types of disc or title recorded on HDD for the type of connected TV When you use the discs recorded either PAL or NTSC, or playback a title recorded on HDD using PAL or NTSC, refer to this table. (Y: Possible, t: Impossible) TV type Disc/Titles recorded on HDD Yes/No PAL Y NTSC Y§1 PAL t NTSC Y§2 PAL Y NTSC Y§3 (PAL60) Multi-system TV NTSC TV PAL TV §1 If you select “NTSC” in “TV System” (➡ page 41), the picture may be clearer.
7462L.book 14 ページ 2004年3月24日 水曜日 午前11時4分 Recording television programmes 2 Time Slip indicator 3 15 Press [W X CH] to select the channel. XP SP REC PLAY LP EP HDD EXT Link OPEN/CLOSE REC TIME SLIP PULL OPEN HDD DVD DRIVE SELECT HDD AV3 S-VIDEO IN VIDEO IN L/MONO AUDIO IN /x1.3 DVD To select with the numbered buttons: e.g.
ページ 2004年3月24日 水曜日 午前11時4分 Recording modes and approximate recording times Playing while you are recording [HDD] [RAM] Depending on the content being recorded, the recording times may become shorter than indicated. (Unit: hour) DVD-RAM HDD DVD-R SingleDoubleMode (80 GB) (4.7 GB) sided sided (4.7 GB) (9.
7462L.book 16 ページ 2004年3月24日 水曜日 午前11時4分 Recording television programmes Refer to the control reference on page 14. Recording from an external equipment Flexible Recording [HDD] [RAM] [DVD-R] The unit sets the best possible picture quality that fits the recording within the remaining disc space. e.g.
7462L.book 17 ページ 2004年3月24日 水曜日 午前11時4分 Timer recording 4 DVD VOLUME CH INPUT SELECT TIMER RECORDING AV HDD Numbered buttons DVD DRIVE SELECT 1 2 3 4 5 6 7 8 9 0 -/-- HDD, DVD G-Code G-Code CANCEL SLOW/SEARCH STOP PAUSE PLAY/x1.
7462L.book 18 ページ 2004年3月24日 水曜日 午前11時4分 Timer recording Refer to the control reference on page 17. [HDD] [RAM] [DVD-R] You can enter up to 32 programmes up to a month in advance. (Each daily or weekly programme is counted as one programme.) Manually programming timer recordings 1 Press [PROG/CHECK]. TIMER RECORDING Remain HDD 30:24 SP DVD 1:58 SP 12:56:00 15. 7. TUE HDD Disc Recording No.
7462L.book 19 ページ 2004年3月24日 水曜日 午前11時4分 Check, change or delete a programme ≥Even when the unit is turned off, you can display the timer recording list by pressing [PROG/CHECK]. Press [PROG/CHECK]. Icons [ This programme is currently recording. W The times overlap those in another programme. Recording of the programme with the later start time starts when the earlier programme finishes recording. F The disc was full so the programme failed to record.
7462L.book 20 ページ 2004年3月24日 水曜日 午前11時4分 Playing discs 1∫ 3 2 ∫ Selecting recorded programmes (titles) to play [HDD] [RAM] [DVD-R] 1 Press [DIRECT NAVIGATOR]. OPEN/CLOSE REC HDD TIME SLIP DVD TIME SLIP HDD DRIVE SELECT /x1.
7462L.book 21 ページ 2004年3月24日 水曜日 午前11時4分 Operations during play Press [∫]. Stop Pause XP SP REC PLAY LP EP HDD The stopped position is memorized. The indicator on the right appears in the unit’s display. (Excluding when playing from the Direct Navigator and when playing a play list.) Resume play function Press [1] (PLAY) to restart from this position. EXT Link Press [;]. Press again to restart play. Press [6] or [5]. Skip Press [:] or [9].
7462L.book 22 ページ 2004年3月24日 水曜日 午前11時4分 Playing discs Refer to the control reference on page 20. Editing operations during play 1 Press [ERASE]. 2 Press [2, 1] to select “Erase” and press [ENTER]. Erase [HDD] [RAM] [DVD-R] ≥A title cannot be restored once it is erased. Make certain before proceeding. ≥You cannot erase while recording or transferring (dubbing). Create Chapter Press [CREATE CHAPTER]. [HDD] [RAM] ≥Press [:, 9] to skip to the start of a chapter.
7462L.book 23 ページ 2004年3月24日 水曜日 午前11時4分 Using menus to play MP3 Using the tree screen to find a group DVD While the file list is displayed TV 1 VOLUME CH INPUT SELECT AV HDD 1 2 3 4 5 6 DVD Selected group no. /Total group no. If the group has no track, “– –” is displayed as group number. CH G-Code 7 8 9 0 -/-- CANCEL MENU G 8 T 14 TOTAL 40/111 MANUAL SKIP SKIP SLOW/SEARCH STOP PAUSE PLAY/x1.3 DIRECT NAVIGATOR No.
7462L.book 24 ページ 2004年3月24日 水曜日 午前11時4分 Using on-screen menus and Status messages Disc menu—Setting the disc content DVD TV Soundtrack§ VOLUME CH INPUT SELECT AV HDD DRIVE SELECT 1 2 3 4 5 6 7 8 9 [HDD] [RAM] [DVD-R] The disc’s audio attributes appear. [DVD-A] [DVD-V] Select the audio and language (➡ below, Audio attribute, Language).
ページ 2004年3月24日 水曜日 午前11時4分 Play menu—Change the play sequence This function works only when the elapsed play time is displayed. Repeat Play Status messages Status messages appear on the television when you operate the unit to show the condition of the unit. Press [STATUS]. ≥All ≥Chapter ≥Group ≥PL (Play list) ≥Title ≥Track [VCD] [CD] (excluding MP3 discs) [HDD] [RAM] [DVD-R] [DVD-V] [DVD-A] [CD] (MP3 discs only) [HDD] [RAM] [HDD] [RAM] [DVD-R] [DVD-V] [DVD-A] [VCD] [CD] Select “OFF” to cancel.
7462L.book 26 ページ 2004年3月24日 水曜日 午前11時4分 Editing titles/chapters Editing titles/chapters and playing chapters DVD TV Preparation ≥Press [HDD] or [DVD] to select the drive. ≥Release protection (cartridge ➡page 12, disc ➡ page 35). [RAM] VOLUME CH INPUT SELECT AV HDD DRIVE SELECT 1 2 3 4 5 6 7 8 9 DVD HDD, DVD 1 2 CH G-Code CANCEL MANUAL SKIP SKIP :, 9 007 SLOW/SEARCH STOP PAUSE PLAY/x1.
7462L.book 27 ページ 2004年3月24日 水曜日 午前11時4分 Title operations Erase§ Press [2, 1] to select “Erase” and press [ENTER]. [HDD] [RAM] [DVD-R] ≥The available recording time on DVD-R does not increase when you erase titles. Information (e.g., time and date) is shown. Properties Properties Dinosaur No.
7462L.book 28 ページ 2004年3月24日 水曜日 午前11時4分 Creating, editing and playing play lists 2 DVD TV PLAY LIST HDD VOLUME CH INPUT SELECT AV HDD Press [3, 4, 2, 1] to select “PLAY LIST” and press [ENTER]. PLAY LIST VIEW -- HDD, DVD DVD DRIVE SELECT 2 -- -- -- Create -- 1 -- 3 CH 4 5 6 7 8 9 0 -/-- Previous G-Code CANCEL MANUAL SKIP SKIP 3 SLOW/SEARCH STOP PAUSE PLAY/x1.
7462L.book 29 ページ 2004年3月24日 水曜日 午前11時4分 Editing and playing play lists/chapters 1 2 3 Play list operations Press [FUNCTIONS]. Erase§ Press [3, 4, 2, 1] to select “PLAY LIST” and press [ENTER]. Press [3, 4, 2, 1] to select the play list. Press [2, 1] to select “Erase” and press [ENTER]. Play list information (e.g., time and date) is shown. Properties Properties Dinosaur No. 10 Chapters 002 To start play ➡ Press [ENTER]. To edit ➡ Step 4.
7462L.book 30 ページ 2004年3月24日 水曜日 午前11時4分 Entering text 1 DVD VOLUME CH INPUT SELECT AV HDD Numbered buttons ¢ CANCEL DRIVE SELECT 1 2 3 4 5 6 7 8 9 Title Select “Enter Name” in step 3 on page 26. DVD Play list Select “Enter Name” in step 4 on page 29. CH Disc Select “Disc Name” in step 3 on page 34. G-Code CANCEL MANUAL SKIP -/-- 0 SKIP SLOW/SEARCH STOP Show Enter Name screen. Title (timer recording) Select “Programme Name” in step 3 on page 17, 18.
7462L.book 31 ページ 2004年3月24日 水曜日 午前11時4分 Transferring (dubbing) titles or play lists [HDD] [RAM] [DVD-R] You can select from a variety of methods to transfer (dub) on this unit. ∫ Transferring (dubbing) direction You can transfer (dub) your favorite titles and play lists to an archive disc. ≥Transferring (dubbing) a play list will create a title. When you want to re-edit finalized content on a DVD-R etc.
7462L.book 32 ページ 2004年3月24日 水曜日 午前11時4分 Transferring (dubbing) titles or play lists Transferring (dubbing) using the transferring (dubbing) list DVD TV [HDD] ,-. [RAM] [HDD] > [DVD-R] You can order titles and play lists for transfer (dubbing) as desired as well as select the speed and picture quality.
7462L.book 7 33 ページ 2004年3月24日 水曜日 午前11時4分 After performing steps 1–4 (➡page 32, right column) Press [3, 4] to select “Start Dubbing” and press [ENTER]. Press [2, 1] to select “Yes” and press [ENTER] to start transferring (dubbing). Transferring (dubbing) list icons 5 Press [3, 4] to select “Dubbing Time” and press [1]. 6 Press [2, 1] to select “Hour” and “Min.” and press [3, 4] to set the recording time.
7462L.book 34 ページ 2004年3月24日 水曜日 午前11時4分 FUNCTIONS window DISC MANAGEMENT [HDD] [RAM] [DVD-R] DVD TV VOLUME CH INPUT SELECT AV HDD DVD DRIVE SELECT 1 2 3 4 5 6 HDD, DVD Preparation ≥Press [HDD] or [DVD] to select the drive. ≥Release protection.
7462L.book 35 ページ 2004年3月24日 水曜日 午前11時4分 Disc Name Top Menu [RAM] [DVD-R] ➡ page 30, Entering text The disc name is displayed in the FUNCTIONS window. FUNCTIONS HDD Documentary Disc Protection Of Cartridge Protectio DVD DVD-RAM Playback DIRECT NAVIGATOR Disc Protection [DVD-R] Prior to finalizing, you can select the background that will be displayed as the DVD-Video top menu after finalizing. ≥You can change thumbnails displayed in the Top menu.
7462L.book 36 ページ 2004年3月24日 水曜日 午前11時4分 Changing the unit’s settings Common procedures < OPEN/CLOSE ∫ 1 While stopped 2 Press [FUNCTIONS]. Press [3, 4, 2, 1] to select “SETUP” and press [ENTER]. OPEN/CLOSE REC HDD TIME SLIP DVD TIME SLIP DRIVE SELECT /x1.
ページ 2004年3月24日 Tabs Disc 水曜日 午前11時4分 Menus Language Choose the language for audio, subtitle and disc menus. [DVD-V] ≥Press [ENTER] to show the following settings. ≥Some discs start in a certain language despite any changes you make here. ≥Enter a code (➡ page 39) with the numbered buttons when you selecting “Other ¢¢¢¢”. When the selected language is not available on the disc, the default language is played. There are discs where you can only switch the language from the menu screen (➡ page 20).
7462L.book 38 ページ 2004年3月24日 水曜日 午前11時4分 Changing the unit’s settings Tabs Sound Menus Options (Underlined items are the factory presets.) PLAY k1.3 & Audio during Search You may hear sound regardless of this setting with some discs. ≥On: Audio is heard during first level search forward. ≥Off: Audio is not heard during search. Quick View (➡page 21) does not work. Dynamic Range Compression [DVD-V] (Dolby Digital only) Change the dynamic range for late night viewing.
ページ 2004年3月24日 Tabs 水曜日 午前11時4分 Menus Options (Underlined items are the factory presets.) ≥16:9 ≥4:3 Progressive (➡ page 10) ≥On ≥Off TV System (➡page 41) ≥PAL ≥NTSC AV1 Output Selects the output from the AV1 terminal. Select “RGB (without component)” for RGB output. Select “Video (with component)” or “S-Video (with component)” for component output.
7462L.book 40 ページ 2004年3月24日 水曜日 午前11時4分 Changing the unit’s settings Refer to the control reference on page 36. ∫ To change the tuning settings for individual programme position Tuning 1 2 3 5 While stopped Press [FUNCTIONS]. Press [3, 4, 2, 1] to select “SETUP” and press [ENTER]. Press [3, 4] to select “Tuning” and press [1]. SETUP Press [3, 4, 2, 1] to select a programme position and press [ENTER].
7462L.book 41 ページ 2004年3月24日 水曜日 午前11時4分 Auto-Setup Restart TV System You can restart auto channel setting if Auto-Setup (➡ page 9) fails for some reason. 4 Press [3, 4] to select “Auto-Setup Restart” and press [ENTER]. Change the settings to match the equipment you are connecting with, or to match the title when there are both PAL and NTSC titles on the HDD. 1 The confirmation screen appears. 5 Press [2, 1] to select “Yes” and press [ENTER]. The country setting menu appears.
7462L.book 42 ページ 2004年3月24日 水曜日 午前11時4分 Changing the unit’s settings Refer to the control reference on page 36. Clock settings In the case of a power failure, the clock setting remains in memory for approximately 60 minutes. 1 2 3 4 While stopped Press [FUNCTIONS]. Press [3, 4, 2, 1] to select “SETUP” and press [ENTER]. Press [3, 4] to select the “Others” and press [1]. Press [3, 4] to select “Clock” and press [ENTER]. Clock Time Date 15 : 45 : 39 1 . 8 . 2004 No.
7462L.book 43 ページ 2004年3月24日 水曜日 午前11時4分 Specifications DVD Video Recording format (DVD-RAM), DVD-Video format (DVD-R) Recordable discs DVD-RAM: 12 cm 4.7 GB, 12 cm 9.4 GB, 8 cm 2.8 GB 12 cm 4.7 GB (Ver. 2.1/3k-SPEED DVD-RAM Revision 1.0) DVD-R: 12 cm 4.7 GB, 8 cm 1.4 GB (for General Ver. 2.0) 12 cm 4.7 GB (for General Ver. 2.0/4k-SPEED DVD-R Revision 1.0) Recording time Maximum 8 hours (with 4.7 GB disc) XP: Approx. 1 hour, SP: Approx. 2 hours LP: Approx. 4 hours, EP: Approx.
7462L.book 44 ページ 2004年3月24日 水曜日 午前11時4分 Glossary Bitstream This is the digital form of multi-channel audio data (e.g., 5.1 channel) before it is decoded into its various channels. CPRM (Content Protection for Recordable Media) CPRM is technology used to protect broadcasts that are allowed to be recorded only once. Such broadcasts can be recorded only with CPRM compatible recorders and discs. Dolby Digital This is a method of coding digital signals developed by Dolby Laboratories.
7462L.book 45 ページ 2004年3月24日 水曜日 午前11時4分 Frequently asked questions Set up What equipment is necessary to play multi channel surround sound? Page ≥DVD-Video: You can play DVD-Video multi channel surround by digitally connecting an amplifier equipped with a Dolby Digital, DTS or MPEG decoder. ≥DVD-Audio: This unit plays DVD-Audio in 2 channels. You cannot play multi channel surround sound. 8 — Are the headphones and speakers directly connected to the unit? ≥You cannot directly connect to the unit.
7462L.book 46 ページ 2004年3月24日 水曜日 午前11時4分 Error messages On the television Page Cannot finish recording completely. ≥The programme was copy-protected. ≥The HDD or disc may be full. — — Cannot playback this title. TV system is different from the setting. To playback this title, please change the TV System in SETUP. ≥You tried to play a title recorded using a different encoding system from that of the TV system currently selected on the unit. Alter the “TV System” setting on this unit to suit.
7462L.book 47 ページ 2004年3月24日 水曜日 午前11時4分 Troubleshooting guide Before requesting service, make the following checks. If you are in doubt about some of the check points, or if the remedies indicated in the chart do not solve the problem, consult your dealer for instructions. The following do not indicate a problem with this unit: ≥Regular disc rotating sounds. The sound of the disc rotating may become louder especially when finalizing a DVD-R. ≥Poor reception due to atmospheric conditions.
7462L.book 48 ページ 2004年3月24日 水曜日 午前11時4分 Troubleshooting guide Sound No sound. Low volume. Distorted sound. Cannot hear the desired audio type. Cannot switch audio. Page ≥Check the connections and settings. Check the input mode on the amplifier if you have connected one. ≥Press [AUDIO] to select the audio. ≥Turn off V.S.S. in the following cases. –When using discs that do not have surround sound effects such as Karaoke discs. –When playing bilingual broadcast programmes.
7462L.book 49 ページ 2004年3月24日 水曜日 午前11時4分 Recording, timer recording and transferring (dubbing) (Continued) Page ≥The timer programme is incorrect or different timer programme times overlap. Correct the programme. ≥The unit is not on timer recording standby. (“F” on the unit’s display is not on.) Press [F TIMER]. ≥Set the clock. 17, 18 Timer recording does not stop even when [∫] is pressed. ≥While using timer recording, press [F TIMER]. (“F” disappears.
7462L.book 50 ページ 2004年3月24日 水曜日 午前11時4分 Troubleshooting guide Edit Cannot format. ≥The disc is dirty. Use a special cleaner and wipe clean. ≥You tried formatting a disc that is not compatible with this unit. 51 12 Cannot create chapters. ≥The unit writes the chapter information to the disc when you turn it off or remove the disc. The information is not written if there is an interruption to the power before this. ≥These operations are not possible with still pictures.
7462L.book 51 ページ 2004年3月24日 水曜日 午前11時4分 Maintenance Unit care The precision parts in this unit are readily affected by the environment, especially temperature, humidity, and dust. Cigarette smoke also can cause malfunction or breakdown. Disc handling ∫ How to hold a disc Do not touch the recorded surface. To clean this unit, wipe with a soft, dry cloth. ≥Never use alcohol, paint thinner or benzine to clean this unit.
7462L.book 48 ページ 2004年3月24日 水曜日 午前11時4分 Index Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Aspect . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Audio Attribute . . . . . . . . . . . . . . . . . . . . . . . 24 Language . . . . . . . . . . . . . . . . . . . . . . 37 Playback . . . . . . . . . . . . . . . . . . . . . . 22 Receiving . . . . . . . . . . . . . . . . . . . . . . 25 Auto Renewal Recording . . . . . . . . . . . 18 Change Thumbnail . . . . . . . . . . . . . . . .
