Applications
1.8
— IOLINK-520 & IOLINK-PRO Installation & Applications Guide
Mandatory Configuration
The IOLINK-520 & IOLINK-PRO requires a minimum amount of mandatory
configuration in order to operate. The following table identifies the configuration
parameters that must be defined for proper operation under the operational states shown in
the table.
Bridge IP Router IPX Router
none IP Address none
ISDN - U ISDN – S/T PPP ISDN
ISDN Switch Type ISDN Switch Type B channel assignment
Directory Numbers Directory Numbers Remote Site Profile
Frame Relay Lease Line PPP Lease Line
none (North America) none none (International)
Remote Site Profile
Frame Relay enabled
(International only)
Frame Relay disabled
(North America only)
The configuration options required for proper initial operation are described in Section 2:
Typical Applications and How to Configure Them. Each configuration requires a different
set of parameters to be entered.
Refer to Section 2 for details on configuring the IOLINK-520 & IOLINK-PRO in different
operational states. Also refer to the IOLINK-520 & IOLINK-PRO VPN Menus Manual
file for your operating software on the accompanying CD-ROM for a complete description
of all the Menu Options.
Other options may be changed depending upon specific installation configurations. Refer to
the menu tree in Appendix A for a reference of the menu structure and options.
