Applications
2.12
— IOLINK-520 & IOLINK-PRO Installation & Applications Guide
IPX Forwarding Enabled
Location: Main
!
Configuration
!
Packet Services Set-up
!
IPX Routing Set-up
!
IPX Forwarding
IPX forwarding must be re-enabled to allow the IOLINK router to
forward IPX frames onto the WAN to the partner IOLINK router IPX
routers.
The IPX Forwarding function enables or disables the forwarding of IPX traffic when
IPX routing is enabled. When IPX forwarding is disabled, all IPX traffic across the
WAN links will be blocked. While IPX forwarding is disabled, the IOLINK router will still
operate as an IPX router and maintain its routing and server tables.
.
2.1.3.3 - Novell Server with Dual LANs
If an IOLINK-520 is configured with two LAN interface modules, the setup will be similar
to the above configuration; the difference being that rather than configuring the IPX
numbers on different IOLINK routers, they are configured on different LANs.
IPX Frame Types
Location: Main
!
Configuration
!
Interfaces Set-up
!
LAN Set-up
select LAN1 or LAN2
!
LAN IPX Set-up
!
Ethernet-II Frames
!
RAW 802.3 Frames
!
IEEE 802.2 Frames
!
802.2 SNAP Frames
The configuration options described here are only for initial set-up and configuration
purposes. For more complete information on all of the configuration parameters available
please refer to the IOLINK-520 & IOLINK-PRO VPN Menus Manual file on the
accompanying CD-ROM.
"
""
"
"
""
"
