Applications
IOLINK-520 & IOLINK-PRO Installation & Applications Guide —
2.47
Remote Site Security Parameters Entry
Location: Main
!
Configuration
!
Connections up
!Edit Remote Site
!
Security Parameters
!
Outgoing User Name
!
Incoming PAP Password
!
Outgoing PAP Password
or
!
Incoming CHAP Secret
!
Outgoing CHAP Secret
The outgoing entries in the security database define the user names and
passwords/secrets that this IOLINK router will send in response to an
authentication request is sent from the remote partner router. The
incoming entries define the passwords/secrets that this IOLINK router
expects to receive from the remote partner in response to authentication
requests.
For a pair of partner routers with security enabled, the outgoing user name in the
security parameters entry of one router must match the remote site alias in the
partner router’s remote sites table.
To use PPP security with frame relay, PPP encapsulation must be enabled. The
PVC must be disabled to change the PPP encapsulation status, then re-enabled.
The configuration options described here are only for initial set-up and configuration
purposes. For more complete information on all of the configuration parameters
available please refer to the IOLINK-520 & IOLINK-PRO VPN Menus Manual file on
the accompanying CD-ROM.
"
""
"
