Introduction to Filtering
3.4
—
IOLINK-520 & IOLINK-PRO000 Installation & Applications Guide
Banyan
Banyan
(12-0BAD)
(12-80C4)
(12-80C5)
IP Router
IP router pattern filters are applied to IP Ethernet frames that are being routed. When the
IOLINK router is operating as an IP router, all IP routed frames will be checked against the
defined IP router pattern filters. IP routed frames are unaffected by the bridge pattern
filters and the IPX router pattern filters.
NetBIOS over TCP
NetBIOS over TCP
NETBIOS Name Service (22-0089)
NETBIOS Datagram Service (22-008A)
NETBIOS Session Service (22-008B)
Note: Uses the TCP Destination Port location
Other interesting TCP Ports
Other interesting TCP Ports
Decimal Hex Usage
21 15 FTP
23 17 Telnet
25 19 SMTP
69 45 TFTP
109 6D POP2
110 6E POP3
