Model No. DRTL99120 Serial No. USER'S MANUAL Serial Number Decal QUESTIONS? If you have questions, or if there are missing or damaged parts, we will guarantee complete satisfaction through direct assistance from our factory. TO AVOID DELAYS, PLEASE CALL DIRECT TO OUR TOLLFREE CUSTOMER HOT LINE. The trained technicians on our Customer Hot Line will provide immediate assistance, free of charge to you. CUSTOMER HOT LINE: 1-800-999-3756 Mon.–Fri., 6 a.m.–6 p.m.
TABLE OF CONTENTS IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
15. Never start the treadmill while you are standing on the walking belt. Always hold the handrails while using the treadmill. 16. The treadmill is capable of high speeds. Adjust the speed in small increments to avoid sudden jumps in speed. 17. Never leave the treadmill unattended while it is running. Always remove the key, unplug the power cord and move the on/off circuit breaker to the off position when the treadmill is not in use. (See the drawing on page 4 for the location of the on/off circuit breaker.
BEFORE YOU BEGIN Thank you for selecting the revolutionary PROFORM® 770 CD treadmill. The 770 CD treadmill combines advanced technology with innovative design to help you get the most from your exercise program in the convenience and privacy of your home. And when you’re not exercising, the unique 770 CD treadmill can be folded up, requiring less than half the floor space of other treadmills. Department toll-free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m.
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. This is a normal condition and does not affect treadmill performance.
3. Attach the Latch Assembly (82) to the Left Upright (84) with the two Latch Screws (134). Start both Latch Screws before tightening either of them. Note: The Latch Screws may be preattached to the Left Upright. 3 82 134 84 4. Refer to step 6 and locate the four Upright Bolts (86). Loosen the Upright Bolts three full turns. 4 With the help of a second person, hold the Console Base (101) near the Uprights (80, 84).
6. Press a CD Holder (85) into each side of the Upright Base (97). If the Wheels (not shown) are touching the floor, or if the treadmill rocks slightly, see HOW TO LEVEL THE TREADMILL on page 20. 6 84 85 85 97 86 80 If you wish to adjust the height of the Uprights (80, 84), go to step 7. If the Uprights are at the desired height, tighten the four Upright Bolts (86) and go to step 8. 97 86 7. Note: The Uprights (80, 84) can be attached at three different heights.
OPERATION AND ADJUSTMENT THE PERFORMANT LUBETM WALKING BELT an equipment-grounding conductor and a grounding plug. Plug the power cord into a surge suppressor, and plug the surge suppressor into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. Important: The treadmill is not compatible with GFCI-equipped outlets. Your treadmill features a walking belt coated with PERFORMANT LUBETM, a high-performance lubricant.
Note: If there are thin sheets of clear plastic on the console, remove them. Clip Key FEATURES OF THE CONSOLE through every step of your workout. High-energy music provides added motivation. Each CD features two programs designed by certified personal trainers. To purchase iFIT.com CD’s, call toll-free 1-800-735-0768. The treadmill console offers an impressive array of features that help you get the most from your workouts.
walking. As you exercise, change the speed of the walking belt as desired by pressing the Speed ▼ and ▲ buttons. Each time a button is pressed, the speed setting will change by 0.1 mph; if a button is held down, the speed setting will change in increments of 0.5 mph. To change the speed setting quickly, press the Quick Speed buttons. Note: The console can display speed and distance in either miles or kilometers. For simplicity, all instructions in this section refer to miles.
To change the unit of measurement, first hold down the Stop button while inserting the key into the console. An “E” for English miles or an “M” for metric kilometers will appear in the Speed display. Press the Speed ▲ button to change the unit of measurement. When the desired unit of measurement is selected, remove the key. 6 Measure your heart rate if desired. You can measure your heart rate using either the handgrip pulse sensor or the optional chest pulse sensor.
The speed setting for the Current Segment first segment is shown in the flashing Current Segment column of the matrix. (The incline settings are not shown in the matrix.) The speed settings for the next seven segments are shown in the seven columns to the right. HOW TO USE PRESET PROGRAMS 1 Insert the key fully into the console. See HOW TO TURN ON THE POWER on page 10. 2 Select one of the preset programs. When the key is inserted, the manual mode will be selected.
To stop the program temporarily, press the Stop button. The Time/Pace display will begin to flash. To restart the program, press the Start button or the Speed ▲ button. To end the program, press the Stop button, remove the key, and then reinsert the key. 4 HOW TO USE HEART RATE PROGRAMS CAUTION: If you have heart problems, or if you are over 60 years of age and have been inactive, do not use the heart rate programs.
4 During heart rate programs, the matrix will show a graphic that represents your heart rate. Each time a heartbeat is detected, an additional peak will appear. automatically increase or decrease to bring your heart rate closer to the target heart rate.
During the CD program, an electronic “chirping” sound will alert you when the speed and/or incline of the treadmill is about to change. CAUTION: Always listen for the “chirp” and be prepared for speed and/or incline changes. In some instances, the speed and/or incline may change before the personal trainer describes the change. HOW TO USE IFIT.COM CD PROGRAMS When you use an iFIT.
6 HOW TO PLAY MUSIC CD’S Follow your progress with the track and the displays. If desired, you can play your own music CD’s in the CD player. Before playing music CD’s, select the manual mode of the console (see HOW TO USE THE MANUAL MODE on page 10). Note: Due to the nature of CD players, the ability of the player to read a CDRW disk while a user is running vigorously on the treadmill may be affected by factors such as the condition of the CD-RW and the quality of the burner used to create the CD-RW.
HOW TO CONNECT THE TREADMILL TO YOUR COMPUTER HOW TO CONNECT THE TREADMILL TO YOUR VCR OR COMPUTER Note: If your computer has a 3.5mm LINE OUT jack, see instruction A. If your computer has only a PHONES jack, see instruction B. HOW TO CONNECT THE TREADMILL TO YOUR VCR A. Plug one end of the audio cable into the jack on the front of the treadmill near the power cord. Plug the other end of the cable into the LINE OUT jack on your computer.
heard, the speed and/or incline will change to the next settings of the video program. HOW TO USE IFIT.COM VIDEO PROGRAMS To stop the walking belt at any time, press the Stop button on the console. The Time/Pace display will begin to flash. To restart the program, press the Start button or the Speed ▲ button. After a moment, the walking belt will begin to move at 1 mph. When the next “chirp” is heard, the speed and incline will change to the next settings of the video program. To use iFIT.
7 HOW TO USE PROGRAMS DIRECTLY FROM OUR WEB SITE When the on-screen countdown ends, the program will begin and the walking belt will begin to move. Hold the handrails, step onto the walking belt, and begin walking. During the program, an electronic “chirping” sound will alert you when the speed and/or incline of the treadmill is about to change. CAUTION: Always listen for the “chirp” and be prepared for speed and/or incline changes.
THE INFORMATION MODE/DEMO MODE HOW TO LEVEL THE TREADMILL The console features an information mode that keeps track of the total number of hours that the treadmill has been operated and the total number of miles that the walking belt has moved. The information mode also allows you to switch the console from miles per hour to kilometers per hour. In addition, the information mode allows you to turn on and turn off the demo mode.
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE 1 Before folding the treadmill, unplug the power cord. CAUTION: You must be able to safely lift 45 pounds (20 kg) in order to raise, lower, or move the treadmill. 1. Hold the treadmill with your hands in the locations shown at the right. To decrease the possibility of injury, bend your legs and keep your back straight. As you raise the treadmill, make sure to lift with your legs rather than your back.
TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department tollfree at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). PROBLEM: The power does not turn on SOLUTION: a.
With the help of a second person, carefully raise the Upright Base (97) as shown. Carefully pivot the Hood (123) off. 97 123 Locate the Reed Switch (22) and the Magnet (19) on the left side of the Pulley (18). Turn the Pulley until the Magnet is aligned with the Reed Switch. Make sure that the gap between the Magnet and the Reed Switch is about 1/8”. If necessary, loosen the Screw (23) and move the Reed Switch slightly. Retighten the Screw.
CONDITIONING GUIDELINES ergy. Only after the first few minutes does your body begin to use stored fat calories for energy. If your goal is to burn fat, adjust the speed and incline of the treadmill until your heart rate is near the lowest number in your training zone. WARNING: Before beginning this or any exercise program, consult your physician. This is especially important for individuals over the age of 35 or individuals with preexisting health problems.
SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible. Hold for 15 counts, then relax. Repeat 3 times. Stretches: Hamstrings, back of knees and back. 1 2. Hamstring Stretch Sit with one leg extended.
PART LIST—Model No. DRTL99120 R0403B To locate the parts listed below, refer to the EXPLODED DRAWING attached in the center of this manual. Key No. Qty. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32* 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 1 12 2 2 2 2 2 2 2 2 4 2 1 2 4 2 2 1 1 8 2 1 1 1 1 1 1 1 1 1 1 1 1 1 2 1 1 4 10 1 1 2 1 3 1 1 1 1 1 1 Description Key No. Qty.
Key No. Qty. 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 1 2 8 1 2 1 1 44 1 1 1 1 1 2 1 1 1 1 1 1 1 1 Description Key No. Qty. Console Base Lift Frame Pivot Nut Ground Screw/Choke Screw Key Clip Fan Screw Fan Console Screw Left Tray CD Console Right Tray iFIT.com Wire iFIT.
62 65 35 66 126 39 70 2 64 16 52 69 1 62 39 8 7 6 5 2 2 126 63 16 13 12 52 68 60 14 11 3 10 9 35 67 15 4 129 2 11 69 42 128 59 11 4 17 2 3 18 9 8 12 10 7 6 5 2 23 11 20 42 21 19 22 28 15 58 115 128 129 130 38 26 37 57 56 55 31 125 118 34 30 14 98 24 27 29 17 20 44 20 52 39 36 33 61 32* 40 39 114 38 20 25 133 41 21 54 103 43 78 132 83 123 52 52 78 45 53 44 52 48 47 46 51 93 50 49 131 7
86 134 90 89* 88 91 79 127 84 82 70 94 92 20 79 87 87 72 81 95 39 96 71 77 86 85 72 99 72 100 91 89* 20 72 80 127 97 135 76 72 94 20 79 90 92 88 87 25 72 103 87 95 72 39 96 20 76 75 103 85 77 74 25 75 107 101 99 135 106 108 100 105 109 105 104 108 108 108 119 108 108 108 110 108 117 108 108 108 120 108 111 108 108 108 116 113 121 44 108 112 108 108 51 108 108 108 108 108 108 108 108 122 124 73 44 108 1
HOW TO ORDER REPLACEMENT PARTS To order replacement parts, call our Customer Service Department toll-free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays).
