www.proform.com Model No. PFTL11011.1 Serial No. Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to www.proformservice.com/ registration. CUSTOMER CARE For service at any time, go to www.proformservice.com. Or call 1-888-533-1333 Mon.–Fri. 6 a.m.–6 p.m. MT Sat. 8 a.m.–4 p.m. MT Please do not contact the store.
TABLE OF CONTENTS WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 BEFORE YOU BEGIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product. 1. It is the responsibility of the owner to ensure that all users of this treadmill are adequately informed of all warnings and precautions. 12.
20. The heart rate monitor is not a medical device. Various factors, including the user’s movement, may affect the accuracy of heart rate readings. The heart rate monitor is intended only as an exercise aid in determining heart rate trends in general. 24. Do not change the incline of the treadmill by placing objects under the treadmill. 25. Never insert any object into any opening on the treadmill. 26. Inspect and properly tighten all parts of the treadmill regularly. 21.
STANDARD SERVICE PLANS all 6
BEFORE YOU BEGIN Thank you for selecting the revolutionary PROFORM® POWER 1080 treadmill. The POWER 1080 treadmill offers an impressive selection of features designed to make your workouts at home more enjoyable and effective. And when you’re not exercising, the unique treadmill can be folded up, requiring less than half the floor space of other treadmills. reading this manual, please see the front cover of this manual.
PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly. Note: If a part is not in the hardware kit, check to see if it is preattached. Extra parts may be included.
ASSEMBLY • To hire a service technician to assemble this product in your home, call 1-800-445-2480. • To identify small parts, see page 8. • Assembly requires the following tools: • Assembly requires two persons. the included hex keys • Place all parts in a cleared area and remove the packing materials. Do not dispose of the packing materials until you nish all assembly steps.
3. Pull the Upright Wire (81) and the base ground wire (A) through the indicated hole in the Base (94). 3 Attach the base ground wire (A) to the Base (94) with a #8 x 1/2" Ground Screw (10). Hole 81 A 94 10 4. Identify the Left Upright (89). Have a second person hold the Left Upright near the Base (94). 4 81 See the inset drawing. Tie the wire tie in the Left Upright (89) securely around the end of the Upright Wire (81).
5. Hold the Left Upright (89) against the Base (94). Be careful not to pinch the Upright Wire (81) or the base ground wire (A). Insert two 3/8" x 1 1/4" Screws (8) with two 3/8" Star Washers (13) and two 3/8" x 2 3/4" Screws (7) into the Left Upright. 5 81 89 Partially tighten the 3/8" x 2 3/4" Screws (7) and the 3/8" x 1 1/4" Screws (8) until the heads of the Screws touch the Left Upright (89); do not fully tighten the Screws yet. Note: Use the short hex key.
7. Cut the plastic ties in the Left Handrail (88) and the Right Handrail (not shown). If necessary, press the 5/16" Cage Nuts (31) back into place. 7 81 Identify the Left Handrail (88) and hold it near the Left Upright (89). Insert the Upright Wire (81) through the bracket on the bottom of the Left Handrail. Pull the Upright Wire out of the end of the Left Handrail. 88 31 Tie 89 8.
9. Set the console assembly face down on a soft surface to avoid scratching the console assembly. Remove the two Screws (A). Next, lift off the Crossbar (93). Discard the two Screws. 9 Console Assembly A 93 10. IMPORTANT: To avoid damaging the Crossbar (93), do not use power tools and do not overtighten the #10 x 3/4" Screws (9) or the #10 x 3/4" Flat Head Screws (28). 10 9 87 93 Orient the Crossbar (93) as shown.
12. Set the console assembly on the Left Handrail (88) and the Right Handrail (87). Be careful not to pinch any wires. Insert the excess Upright Wire (not shown) into the Left Handrail. Attach the console assembly with six #8 x 1/2" Screws (1) and four 1/4" x 1/2" Screws (36) with four 5/16" Flat Washers (27) and four 1/4" Star Washers (35) as shown. Start all ten Screws, and then tighten them. See step 8. Fully tighten the four 5/16" x 1" Screws (5) and the two 5/16" x 1 1/4" Bolts (4). 13.
. Hold the Left Upright Cover (79) against the console assembly. Align the holes in the Left Upright Cover with the holes in the Left Upright (89). Attach the Left Upright Cover with three #8 x 1/2" Screws (1). 15 Attach the Right Upright Cover (80) to the Right Upright (90) in the same way. 1 80 79 Console Assembly 1 1 90 16. Attach the Left Tray (107) and the Right Tray (102) to the console assembly with four #8 x 1/2" Screws (1).
17. IMPORTANT: See page 18 and plug in the power cord. Next, see page 20 and turn on the power. 17 IMPORTANT: Make sure to follow all instructions in this step. Then, see step 1 on page 27 and step 2 on page 29 to access the maintenance mode. Then, follow step 4 on page 29 to calibrate the incline system of the treadmill. When the frame stops moving, remove the key from the console and unplug the power cord. 18.
19. Attach the Rear Feet (57) to the Frame (56) as shown with four #8 x 3/4" Screws (2). 19 Lower the Frame (56) (see HOW TO LOWER THE TREADMILL FOR USE on page 31). 57 57 2 2 56 20. Press the Grommet (77) into the square hole in the Base (94). 20 94 77 21. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of plastic on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the treadmill.
OPERATION AND ADJUSTMENT HOW TO CONNECT THE POWER CORD nominal 120-volt circuit capable of carrying 15 or more amps. To avoid overloading the circuit, do not plug other electrical devices, except for lowpower devices such as cell phone chargers, into the surge suppressor or into an outlet on the same circuit. IMPORTANT: The treadmill is not compatible with GFCI-equipped outlets and may not be compatible with AFCI-equipped outlets.
CONSOLE DIAGRAM MAKE YOUR FITNESS GOALS A REALITY WITH IFIT.COM FEATURES OF THE CONSOLE The advanced treadmill console offers an array of features designed to make your workouts more effective and enjoyable. With your new iFit-compatible fitness equipment, you can use an array of features on iFit.com to make your fitness goals a reality: When you use the manual mode, you can change the speed and incline of the treadmill with the touch of a button.
HOW TO TURN ON THE POWER HOW TO USE THE TOUCH SCREEN IMPORTANT: If the treadmill has been exposed to cold temperatures, allow it to warm to room temperature before turning on the power. If you do not do this, you may damage the console displays or other electrical components. The console features a tablet with a full-color touch screen. The following information will help you become familiar with the tablet’s advanced technology: Plug in the power cord (see page 18).
HOW TO SET UP THE CONSOLE The console is now ready for you to begin working out. The following pages explain the various workouts and other features that the console offers. Before using the treadmill for the first time, set up the console. To use the manual mode, see page 22. To use an onboard workout, see page 24. To use a set-a-goal workout, see page 25. To use an iFit workout, see page 26. 1. Connect to your wireless network.
HOW TO USE THE MANUAL MODE the numbered Quick Incline buttons. Each time you press one of the buttons, the incline will gradually change until it reaches the selected incline setting. 1. Insert the key into the console. See HOW TO TURN ON THE POWER on page 20. Note: It may take a minute for the console to be ready for use. Note: The first time you adjust the incline, you must first calibrate the incline system (see step 4 on page 29). 2. Select the main menu. 5. Monitor your progress with the displays.
If desired, adjust the volume by pressing the volume increase and decrease buttons on the console. Press the fan increase Increase button to increase the fan speed. Note: If you press the fan increase button once while the fan is on its maximum speed setting, the Decrease auto fan mode will be selected. Press the fan decrease button repeatedly to decrease the fan speed or to turn off the fan. Increase Decrease To pause the workout, touch one of the menu buttons or press the Stop button on the console.
HOW TO USE AN ONBOARD WORKOUT If the speed and/or incline settings are too high or too low at any time during the workout, you can override the settings by pressing the Speed or Incline buttons. If you press a Speed button, you can then manually control the speed (see step 3 on page 22). If you press an Incline button, you can then manually control the incline (see step 4 on page 22). To return to the programmed speed and/or incline settings of the workout, touch the Follow Workout button. 1.
HOW TO USE A SET-A-GOAL WORKOUT The workout will function in the same way as the manual mode (see pages 22 and 23). 1. Insert the key into the console. The workout will continue until you reach the goal that you set. The walking belt will then slow to a stop, and a workout summary will appear on the screen. After you view the workout summary, touch the Finish button to return to the main menu. You may also be able to either save or publish your results using one of the options on the screen.
HOW TO USE AN IFIT WORKOUT Before some workouts will download, you must add them to your schedule on iFit.com. Note: To use an iFit workout, you must have access to a wireless network (see HOW TO USE THE WIRELESS NETWORK MODE on page 30). An iFit account is also required. For more information about the iFit workouts, please see www.iFit.com. When you select an iFit workout, the screen will show the name, duration, and distance of the workout.
HOW TO USE THE EQUIPMENT SETTINGS MODE IMPORTANT: You must still unplug the power cord after using the treadmill. Set the update time for a time when you normally use the treadmill and will be available to unplug the power cord after an update. 1. Select the settings main menu. Insert the key into the console (see HOW TO TURN ON THE POWER on page 20). Next, select the main menu (see step 2 on page 22). Then, touch the gears button near the lowerright corner of the screen to select the settings main menu.
11. Enable or disable a passcode. Next, press the play button on your MP3 player, CD player, or other personal audio player. Then, adjust the volume level on your personal audio player or press the volume increase and decrease buttons on the console. The console features a child-safety passcode, designed to prevent unauthorized users from using the treadmill. Touch the Passcode button. To enable a passcode, touch the Enable checkbox. Then, enter a 4-digit passcode of your choice.
HOW TO USE THE MAINTENANCE MODE Note: Occasionally, a firmware update may cause your console to function slightly differently. These updates are always designed to improve your exercise experience. 1. Select the settings main menu. See step 1 on page 27. 4. Calibrate the incline system of the treadmill. 2. Select the maintenance mode. Touch the Calibrate Incline button. Then, touch the Begin button to calibrate the incline system.
HOW TO USE THE WIRELESS NETWORK MODE An information box will ask if you want to connect to the wireless network. Touch the Connect button to connect to the network or touch the Cancel button to return to the list of networks. If the network has a password, touch the password entry box. A keyboard will appear on the screen. To view the password as you type it, touch the Show Password checkbox. The console features a wireless network mode that allows you to set up a wireless network connection. 1.
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline to the lowest position before you fold the treadmill. Then, remove the key and unplug the power cord. CAUTION: You must be able to safely lift 45 lbs. (20 kg) to raise, lower, or move the treadmill. Before moving the treadmill, fold it as described at the left. CAUTION: Make sure that the latch knob is locked in the storage position.
TROUBLESHOOTING Most treadmill problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, see the front cover of this manual. SYMPTOM: The console screen remains lit when you remove the key from the console a. The console features a display demo mode, designed to be used if the treadmill is displayed in a store. If the screen shows a preset presentation when you remove the key, the demo mode is turned on.
SYMPTOM: The walking belt slows when walked on SYMPTOM: The walking belt is off-center or slips when walked on a. Use only a surge suppressor that meets all of the specifications described on page 18. a. If the walking belt is off-center, first remove the key and UNPLUG THE POWER CORD.
EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exercise at a low intensity level for a sustained period of time. During the first few minutes of exercise, your body uses carbohydrate calories for energy. Only after the first few minutes of exercise does your body begin to use stored fat calories for energy. If your goal is to burn fat, adjust the intensity of your exercise until your heart rate is near the lowest number in your training zone.
PART LIST Key No. Qty. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 18 55 1 2 4 1 4 4 2 7 4 2 4 21 2 1 2 2 9 2 2 2 4 1 4 11 4 2 1 4 2 2 6 4 7 4 1 2 4 4 1 1 1 1 1 2 2 4 1 1 1 1 1 Model No. PFTL11011.1 R0113A Description Key No. Qty.
15 39 40 14 2 38 37 36 59 30 34 23 14 39 61 40 2 2 26 57 60 45 43 15 47 44 2 42 23 46 26 26 2 2 19 2 57 59 30 34 30 34 2 12 56 26 59 21 2 38 47 40 39 26 2 23 51 14 6 2 2 49 14 50 52 18 26 55 40 39 41 19 14 2 2 10 53 12 24 35 59 30 34 26 46 23 20 21 10 48 54 3 18 EXPLODED DRAWING A Model No. PFTL11011.
EXPLODED DRAWING B Model No. PFTL11011.
EXPLODED DRAWING C Model No. PFTL11011.
EXPLODED DRAWING D Model No. PFTL11011.
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual.
