Installation Guide

5
4
ASSEMBLY INSTRUCTIONS
1
2
3
Hex nut
Chain
Chain
Wire nut
Mounting screw
Ring
Ring
Washer
Screw collar loop
Screw collar loop
Threaded nipple
Threaded nipple
Threaded nipple
Mounting bar
Canopy
Canopy
1.
Hardware Used
Hardware Used
Hardware Used
Hardware Used
Attach the mounting bar (II) by tightening the
mounting screws (CC) securely into the outlet
box (not included). The threaded nipple (HH)
should protrude away from the outlet box.
Turn the hex nut (AA) clockwise to tighten the
threaded nipple (HH) and washer (GG) onto
the mounting bar (II).
3. Attach wire nuts (BB). Tape wire nuts (BB)
and wires together.
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
AA
DD
DD
BB
CC
EE
EE
GG
FF
FF
HH
HH
HH
II
JJ
JJ
BB
ASSEMBLY INSTRUCTIONS
4
5
6
6. Take off check ring (B), install the glass
shade (C) over the socket, and then secure
with check ring (B).
2. Strip 3/4 in. of insulation from wire ends. Pass
the wire through the chain (DD), ring (EE),
screw collar loop (FF), canopy (JJ) and
threaded nipple (HH). Twist stripped ends
together with pliers, black to the wire with
smooth surface (power) and white to the wire
with longitudinal ridges (neutral). Attach
copper wire to ground wire. Helpful hint: If
necessary, attach copper ground wire to
grounded junction box.
I I
CC
HH
GG
AA
x 1
x 2
x 1
x 1
x 1
HH
FF
JJ
DD
EE
x 1
x 1
x 1
x 1
x 1
x 1
x 1
x 1
x 1
x 1
x 3
A
D
C
B
Lowes.com Lowes.com
A
JJ
FF
HH
EE
DD
5. Install screw collar loop (FF) into threaded
nipple (HH). Place the canopy (JJ) into screw
collar loop (FF) and secure with ring (EE).
Open the top section of the chain (DD), then
attach it to the screw collar loop (FF).
Open the bottom section of the chain (DD), then
