Specifications
Features
Bar coding for ease of installation
Automatic configure and remote setup
Anti-tamper switch detects opening of lid, also external connection
provided.
All connections removable (except CON5, LIVE and NEUTRAL) screw
terminal blocks
128 Presets, all functions. Preset resolution, 10-bit
Random Pan / Patrol / Electronic end stops
Test button
Lens Drives
Zoom, focus and iris, 10V DC (max 100mA)
Network
Plug in network PCB, PY-FTT, PY-485, PY-422, PY-F17, PY-F19
Relays
P/T head relays
4 auxiliary relays for wash, wipe, lamps and camera power
Relay outputs Max 240 V at 1A
Fuse 10 Amp Anti-Surge
Video:
Via BNC connectors
Video 1V pk-pk PAL/NTSC
Max Gain >5dB
Max Lift >4dB at 4MHz
Power
Board Power 12V DC ± 10%, 1A class 2
Relay Power max 240V AC, 10A
Nominal Consumption 8.5 Watts (12V DC)
Physical
Weight 5 kg
PCB Weight 0.5kg
