Operating instructions

Page 2
Product Safety
Please follow these instructions as you install your pyramid module and
keep them for future use. If you have any problems contact your Baxall
agent.
WARNING: Installation is only to be carried out by competent,
qualified and experienced personnel
WARNING: Wire in accordance with your national wiring regulations.
Failure to do so can result in injury or death by electric shock
WARNING: Use a class 2 isolated power supply for the 12V DC
Definitions
Mains - this refers to the mains supply voltage labelled on your AC
receiver power supply
P/T head - Pan and Tilt Head
LIVE and NEUTRAL refer to mains
SUPPLY and RETURN are used to refer to 24V AC
Product Reliability
CAUTION: Your module is susceptible to damage from Electrostatic
Discharge (ESD)). Take normal ESD precautions when handling your
network card. ESD prevention kits are available from most electronics
distributors.
CAUTION: Do not exceed the voltage and temperature limits given in
the specification.
CAUTION : Switch off the power before fitting a network card.
