Operating instructions

Page 8
Referring to figure 1, connect the video from your camera to VIDEO IN,
through your AC receiver, then from VIDEO OUT to the matrix.
NETWORK
CAUTION
: To avoid damaging your module switch off the power
before fitting the network card
Switch off the power, fit a network card in the position indicated on
figure 1.
Connect the cable provided from the network card to the filter board
mounted on the metal base plate.
Connect the network to the filter card. The wiring diagram is included on
the sheet provided with the network cards.
POWER
WARNING
: Ensure that the power is switched off before connecting
the mains wires
WARNING : Your PY-ACW module must be earthed
Connect the Live, Earth and Neutral wires from the mains supply to Live,
Earth and Neutral on the external terminal block.
Check that all the wiring is correct and switch on the power.
WARNING : Your AC receiver PCB now contains live voltages
LED Power Indicator
LED1 (see figure 1) indicates the polarity of the 12V DC. For correct
polarity it is green, incorrect it is red.
