FCD-IPM Installation and Operation Manual Chapter 5 Setup Menu
Interface Parameters Menu 5-33
For the I/O Data Channel slots, additional card options are available. Refer to
Chapter 1.
Link1
FCD-IPM
Router/Bridge
E1/T1
Service
Figure 5-38. FCD-IPM with an E1/T1 Interface
Link1
FCD-IPM (E1/T1 with Sub Link)
Router/Bridge
Sub Link
E1/T1
Service
E1/T1 Service
or PABX
Figure 5-39. FCD-IPM with an E1/T1 Interface and Sublink
Link1
FCD-IPM (E1/T1 with Analog Voice Ports)
Router/Bridge
E1/T1
Service
Voice
Card
Figure 5-40. FCD-IPM with an E1/T1 Interface and Analog Voice Ports
FCD-IPM with sublink provides a drop & insert capability. The drop & insert
capability enables multiplexing of data from the local router/bridge, and voice from
the local PABX, to the E1/T1 main link. The I/O Data channels function with the
same logic.
